| 型号 | A | B | C | D | 包装 | |
| mm | inch | |||||
| CC-1SS | 6.5 | 3.8 | 3.2 | 1/8 | 6.8 | 1000 |
| CC-1S | 9.2 | 5.4 | 3.2 | 1/8 | 8.2 | |
| CC-1 | 13.2 | 5.4 | 3 | 1/8 | 8.9 | |
| CC-2 | 10 | 5.4 | 4.5 | 3/16 | 10.2 | |
| CC-3 | 9.3 | 5 | 6.2 | 1/4 | 10.2 | |
| CC-4 | 9.5 | 5 | 7.6 | 5/16 | 10.5 | |
| CC-4L | 9.2 | 5.4 | 8 | 5/16 | 10.7 | |
| CC-5 | 9.5 | 4.8 | 9 | 3/8 | 12.4 | |
| CC-5L | 12.3 | 5.4 | 9 | 3/8 | 13.2 | 500 |
| CC-6 | 12.7 | 4.8 | 11.5 | 1/2 | 14.7 | |
| CC-7 | 12.9 | 5.4 | 12.8 | 1/2 | 16 | |
| CC-7S | 12.5 | 4.8 | 15.5 | 5/8 | 16.7 | |
| CC-8 | 12.9 | 5.4 | 17 | 3/4 | 19.6 | 200 |
| CC-9 | 12.9 | 5.4 | 20 | 7/8 | 21.2 | 250 |
| CC-10 | 12.9 | 5.4 | 24~27 | 1/8 | 23.5 | 200 |
| CC-12 | 9.9 | 4.4 | 3 | 1/8 | 8.5 | 1000 |
| CC-13 | 9.5 | 3.2 | 8.3 | 5/16 | 12 | |
| CC-14 | 6.3 | 3.7 | 3.5 | 1/7 | 6.4 | |
| CC-15 | 9.6 | 4.4 | 5.6 | 1/4 | 12.1 | |
| CC-16 | 11.6 | 6.4 | 5.6 | 1/4 | 12.1 | |
| CC-17 | 10 | 4.2 | 5 | 1/4 | 9.5 | |
| CC-18 | 10 | 4.2 | 11 | 7/16 | 13 | |
| CC-19 | 9.9 | 4.4 | 4.5 | 3/16 | 7.75 | |
| CC-20 | 10 | 4.3 | 6.5 | 1/4 | 9.9 | |
| CC-31 | 10 | 4.2 | 11.5 | 1/2 | 14 | |
| CC-32 | 10 | 4.2 | 5 | 1/4 | 9.5 | |
| CC-35 | 6.5 | 3.3 | 3 | 1/8 | 9.5 | |
| CC-37 | 10.9 | 5 | 7.5 | 5/16 | 10.5 | |
| CC-38 | 12.9 | 6.6 | 7.5 | 5/16 | 10.5 | |
| CC-44 | 10 | 3.5 | 4.5 | 3/16 | 10.2 | |
| CC-50 | 4 | 2.5 | 3.1 | 1/8 | 6 | |
| CC-51 | 12.7 | 5.2 | 9.5 | 3/8 | 12.3 | |
| CC-59 | 12.7 | 5.2 | 31.75 | 1/4 | 26.9 | 250 |
| 型号 | C | D | E | 包装 |
| CC-28 | 1000 | |||
| CC-55 | 1000 | |||
| CC-25 | 3.2 | 9.86 | 17 | 500 |
| CC-26 | 4.8 | 11.1 | 19 |
| 型号 | F | 包装 |
| CC-24 | 5.4 | 500 |
| CC-45 | 4.4 | |
| CC-21 | 500 | |
| CC-53 | 1000 |
| 型号 | 包装 |
| CC-29 | 1000 |
| CC-42 | 1000 |
| CC-54 | 1000 |
| 型号 | Package |
| CC-56 | 1000 |
| CC-23 | 500 |
| CC-57 | 1000 |
| 型号 | 包装 |
| CC-46 | 1000 |
| CC-49 | 500 |
| CC-58 | 1000 |
| 型号 | 包装 |
| CCP-2 | 1000 |
| CCF-1 | 1000 |
